Alber E-PILOT P15 – Electric Motor for Wheelchairs

Practical – It is an innovative, safe and reliable device. It easily adapts to manual wheelchairs, transforming them into electric chairs for a more active lifestyle and less effort for the user.

Useful – It is an ideal everyday aid and can be mounted on the chair whenever necessary. It is a smart electric device for active wheelchair users.

Who it is for – It can only be used by people who:
– Can coordinate and move both hands or arms without major restrictions;
– Have the physical and psychological capacity to control the wheelchair with the e-pilot, move on public roads, brake and immobilize the chair safely in case of equipment failure.

Promotes personal autonomy – Increases mobility and flexibility, providing greater autonomy and independence.

Autonomy – Up to 50 km.

Easy to use – Easy to install and remove from the e-pilot P15. Can be used every day.

Easy storage – Allows for simple and practical storage.

Driving unit – Aluminum structure with integrated lithium-ion batteries, 50 km autonomy and speed up to 10 km/h.

The wide 16’’ front wheel allows for riding on uneven surfaces.

It also includes reverse gear.

On the handlebars, you'll find the accelerator, lights, horn, reverse gear, and USB input for charging devices.

Batteries – Self-contact, quick-release battery pack, with up to 50 km autonomy.

Battery charging – Approximately 4 hours for a full charge.

Display – Detachable color display with battery indication, speed, and travel data. Easy to remove with a magnetic twist-lock mechanism.

Compatibility – Wheelchair measurements must be confirmed:
– Chair width
– Back height
– Front height
– Front frame angle
– Seat to footrest measurement
– Footrest type
– Brake type

Mobility App – Allows you to check battery capacity, autonomy, and fault warnings on your mobile phone. Compatible with Android and iOS via Bluetooth.

Benefits of the Alber e-pilot P15 front wheel:
– Easy to maneuver
– Transforms a manual chair into an electric one
– Can be adapted to manual chairs (subject to verification)
– Allows riding on uneven surfaces
– Can be managed via smartphone
– Autonomy up to 50 km

Recommendations:
– Confirm chair measurements to verify compatibility
– Avoid driving in sand, mud, snow, ice, or deep water
– Avoid water infiltration into the motor or battery
– Do not use under running water or with high-pressure washing

Diversity of wheelchair choices – Loja do Avô offers several models. Contact us.

Accessories and options – May include:
– Basket
– Bottle holder
– Backpack
– Mirrors

Features:
– Maximum user weight: 100 kg
– Motor: 250W (650W peak)
– Speed: up to 10 km/h
– Maximum obstacle height: 5 cm
– Battery: 36V, 13.8 Ah
– Capacity: 496 Wh
– Type: lithium-ion
– Autonomy: up to 50 km
– Battery weight: 3.4 kg
– Weight with battery: 18.4 kg
– Weight without battery: 15.5 kg

Warranty – According to current legislation.
